20W triac dimmable Led driver（Waterproof series）
20W triac dimmable Led driver（Waterproof series）
- Brand： ???HUEUC
- Model： ???DR-CC-20 DR-CV-20
Input voltage:110V/AC & 230V/AC
Output Constant current：350MA&700MA&900MA (by customer's requirement)
Output Constant voltage：12V/24V/36V/48V
Output power：20W Working efficiency：85%
Constant current accuracy:5%
Power factor：>0.95
Dielectric strength：3750V
Constant current LED load：3W（4-6 pcs） / 1W（8-12 pcs）
Constant voltage LED load::12V/24V/36V/48V LED strip
12V/24V/36V/48V LED spot
Working temperature:-25℃~55℃
Size:114*42*33mm
Warranty:5 years
Waterproof lever:IP67
Our products have passed CE,ETL,TUV,3C and SAA certification.It can be applied to indoor and ourdoor lighting.
The range of triac dimming mode is from 5% to 100% without flashing.Constant current series can be used to driver Downlight,spotlight,panel light and etc.Constant voltage series can be used to driver light bar,spotlight MR16 and etc.
We also can adjust the output current and output voltage even non-dimming by your requirement.
